Power analyzer for multi-parameter measurement in the research and development of new energy vehicles

2025-06-25

At present, as the global automotive industry accelerates its transformation towards green and intelligent directions, new energy vehicles have become the core direction of the future development of the automotive industry due to their significant advantages such as environmental protection and efficiency. The research and development of new energy vehicles is a complex and systematic project, involving multiple key areas such as electrical systems, power systems, and control systems. Accurately obtaining various parameters of the electrical system during this process is crucial for gaining a deeper understanding of vehicle performance, optimizing system design, and improving research and development efficiency. As a powerful testing device, power analyzer plays an irreplaceable role in the research and development experiments of new energy vehicles. Its multi parameter measurement capability provides comprehensive and in-depth data support for R&D personnel.


Technical basis for multi parameter measurement of power analyzer

The reason why power analyzers can achieve multi parameter measurement is due to their advanced hardware design and precise algorithm processing. In terms of hardware, it is equipped with high-precision voltage sensors, current sensors, and high-speed data acquisition modules. Voltage sensors can accurately capture the voltage signals of different nodes in the electrical system, whether it is the high voltage output of the battery pack or the low voltage signal inside the electronic control unit, they can be accurately measured. Current sensors can monitor the current in the circuit in real-time, whether it is direct current or alternating current, and can collect data with high resolution and accuracy. The high-speed data acquisition module ensures the rapid and continuous acquisition of a large amount of voltage and current data, providing rich raw materials for subsequent analysis.


In terms of algorithm processing, the power analyzer utilizes advanced digital signal processing technology. By filtering and Fourier transforming the collected voltage and current signals, multiple parameters such as power, frequency, and phase can be accurately calculated. For example, Fourier transform can be used to convert time-domain voltage and current signals into frequency-domain signals, thereby analyzing the content of different frequency components in the signal, which is of great significance for studying harmonic problems in electrical systems. Meanwhile, the power analyzer can also calculate instantaneous power based on the instantaneous values of voltage and current, and obtain average power parameters such as active power, reactive power, and apparent power through integration and other operations, providing accurate basis for evaluating the energy conversion efficiency of electrical systems.


Application of Multi Parameter Measurement in the Analysis of Battery Charging and Discharging Characteristics

As the energy storage core of new energy vehicles, the charging and discharging characteristics of batteries directly affect the performance and range of the vehicle. The power analyzer can measure multiple key parameters in real-time during battery charging and discharging experiments, providing a powerful means for in-depth research on battery characteristics.


During the charging process, the power analyzer can measure the charging voltage, charging current, and charging power of the battery. By monitoring changes in charging voltage, the charging status and efficiency of the battery can be understood. For example, in the constant current charging stage, the charging voltage will gradually increase with the increase of battery power. When it reaches a certain voltage value, it enters the constant voltage charging stage, and the charging current will gradually decrease. The power analyzer can accurately record the changes in voltage and current, helping R&D personnel optimize charging strategies, improve charging efficiency, and avoid overcharging of the battery, thereby extending its service life.


In addition, the power analyzer can also measure the energy loss during battery charging. By calculating the difference between the input power and the actual energy stored in the battery, the impact of factors such as heat loss and circuit loss during the charging process on energy conversion efficiency can be analyzed. This is of great significance for the development of efficient battery charging systems.


During the discharge process, the power analyzer also plays an important role. It can measure the discharge voltage, discharge current, and discharge power of the battery to evaluate its discharge performance. For example, by analyzing the variation curve of discharge voltage, the internal resistance of the battery can be understood. As the battery level decreases, the internal resistance gradually increases, leading to a decrease in discharge voltage. The power analyzer can monitor these changes in real time, providing accurate data support for battery capacity estimation and remaining power prediction. Meanwhile, by measuring the discharge power, the output capability of the battery under different load conditions can be evaluated, providing reference for the power system design of new energy vehicles.


Application of multi parameter measurement in motor load characteristic analysis

The motor is the power output core of new energy vehicles, and its load characteristics directly affect the vehicle's power performance and energy utilization efficiency. The power analyzer can measure multiple parameters of the motor, such as input voltage, input current, input power, and output power, in motor load experiments, providing important basis for the analysis and optimization of motor characteristics.


During the operation of the motor, the power analyzer can measure the input voltage and current of the motor in real time, and calculate the input power. By analyzing the changes in input power, the energy consumption of the motor under different load conditions can be understood. For example, when the motor load increases, the input power will correspondingly increase, but excessive input power can lead to energy waste and motor heating. Power analyzer can help R&D personnel find the optimal input power point of the motor under different loads, improving the energy utilization efficiency of the motor.


Meanwhile, the power analyzer can also calculate the output power and efficiency of the motor by measuring its speed and torque, combined with the input power. The output power reflects the power output capability of the motor, while efficiency reflects the motor's ability to convert electrical energy into mechanical energy. By analyzing the variation curves of output power and efficiency, the load characteristics of the motor can be understood, and the high-efficiency operating range of the motor can be identified. This is of great significance for optimizing the control strategy of the motor, improving the power performance and range of new energy vehicles.


In addition, the power analyzer can also detect harmonic problems during the operation of the motor. The motor may generate harmonic currents and harmonic voltages during operation, which can cause interference to the electrical system and affect the normal operation of other equipment. Power analyzers can analyze the content and frequency distribution of harmonics through algorithms such as Fourier transform, helping researchers take corresponding filtering measures to improve the stability and reliability of electrical systems.


The comprehensive value of multi parameter measurement of power analyzer for the development of new energy vehicles

The multi parameter measurement capability of power analyzers provides comprehensive and in-depth data support for the research and development of new energy vehicles, and has multifaceted comprehensive value.


In the initial stage of research and development, by measuring multiple parameters of key components such as batteries and motors, R&D personnel can gain a deep understanding of their performance characteristics, providing a basis for the preliminary design and selection of the system. For example, selecting appropriate battery capacity and motor power based on the charging and discharging characteristics of the battery and the load characteristics of the motor ensures that the vehicle's power performance and range meet the design requirements.


During the research and development process, power analyzers can monitor the operational status of electrical systems in real-time and promptly identify potential issues. For example, by monitoring abnormal fluctuations in voltage and current, it is possible to determine whether there are faults such as short circuits or open circuits in the circuit; By analyzing the harmonic content, the electromagnetic compatibility of electrical systems can be evaluated. This helps R&D personnel adjust design plans in a timely manner, optimize system performance, and improve R&D efficiency.


In the later stage of research and development, the multi parameter measurement data of power analyzers can provide important basis for product performance evaluation and certification. By comprehensively testing the power, voltage, current and other parameters of the vehicle under different operating conditions, it is possible to verify whether the vehicle complies with relevant standards and specifications, and prepare for the product's launch and sale.


The multi parameter measurement capability of power analyzers in the research and development experiments of new energy vehicles is an important tool for promoting technological progress in new energy vehicles. It provides strong support for research on battery charging and discharging characteristics, motor load characteristics, and other aspects through precise measurement and comprehensive analysis of multiple parameters such as voltage, current, power, and frequency, and provides comprehensive data guarantee for the development, optimization, and certification of new energy vehicles. With the continuous development of new energy vehicle technology, the functions and performance of power analyzers will also be continuously improved, injecting new impetus into the development of the new energy vehicle industry.
